Wastewater/Activity/PacpInspection/1.0Mar 21, 2017, 05:47 AM
A 0593_A 0592_032017_224800.mp4
- Date
- 03/20/2017
- W/O
- 607686
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00316
- PipeID
- P07798
- Time
- 10:47 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4325
- Sewer Name
- A JOA-1A DISTRICT 21 INTERCEPTOR
- City
- CITY OF INDUSTRY
- Loc. details
- Easement/Right of Way
- Location Code
- D
- Use of Sewer
- Sanitary Sewer
- District
- District 15
- Page No.
- 34
- Purpose
- Routine Assessment
- Project
- WO_607686_TV21041_MAR2017
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 48 in.
- Width
- 48 in.
- Upstream MH
- A 0593
- Downstream MH
- A 0592
- Dir. of Survey
- Downstream
- Length Surveyed
- 430.5 ft.
- Total Length
- 430.5 ft.
- Structural Index
- 3
- Structural Quick
- 3O2O
- Structural Rating
- 410
- O&M Index
- 2
- O&M Quick
- 2O00
- O&M Rating
- 164
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 574
Observation photos (3)
18.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
18.1 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
18.1 ft. - Surface Aggregate Visible, at 08 o'clock, within 8 inches of joint: YES, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 18.1 | DAGS | — |
| 18.1 | SSS | — |
| 430.5 | SSS | — |
| 0 | MWL | — |
| 430.5 | SAV | — |
| 145 | TF | — |
| 430.5 | MSA | FLOAT FLIPPED DUE TO TURBULENT WATER |
| 18.1 | SAV | — |
| 430.5 | DAGS | — |
| 0 | AMH | A 0593 |
| 0 | MWM | — |
Properties (5)
- additional_info
- SC318740
- custom_field_two
- 5
- customer
- LACSD
- datetime
- 2017-03-20T22:47:16-07:00
- sewer_category
- Gravity
