Wastewater/Activity/PacpInspection/1.0Apr 25, 2017, 06:41 AM
21 0452_21 0451 _20170425_001720.mp4
- Date
- 04/24/2017
- W/O
- 630321
- Weather
- Dry
- Operator/Surveyor
- JUAN B
- Sewer ID
- Z00777
- PipeID
- P15661
- Time
- 11:41 PM
- Certificate
- U-715-07000770
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K4513
- Sewer Name
- 21 MOUNT SAN ANTONIO TRUNK
- City
- WALNUT
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 21
- Page No.
- 28
- Purpose
- Routine Assessment
- Project
- WO_630321_TV21046_APR2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 21 0451
- Downstream MH
- 21 0452
- Dir. of Survey
- Upstream
- Length Surveyed
- 232.3 ft.
- Total Length
- 232.3 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2300
- O&M Rating
- 6
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 9
Observation photos (2)
5.4 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
6 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 6 | CM | — |
| 0 | MWL | — |
| 0.1 | MWM | — |
| 60.2 | TBC | — |
| 162.5 | TBC | — |
| 232.3 | DAGS | — |
| 0 | AMH | 21 0451 |
| 232.3 | CM | — |
| 232.3 | AMH | 452 |
| 201.1 | TBA | — |
| 5.4 | DAGS | — |
| 104.2 | TB | — |
Properties (5)
- additional_info
- SC340727
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-04-24T23:41:50-07:00
- sewer_category
- Gravity
