Wastewater/Activity/PacpInspection/1.0Mar 6, 2017, 11:59 AM
05 0774_05 0773 _06032017_035954.mp4
- Date
- 03/06/2017
- W/O
- 624365
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00553
- PipeID
- P06001
- Time
- 3:59 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4367
- Sewer Name
- 05 MANCHESTER-VERMONT DIVERSION EXTENSION TRUNK
- City
- LOS ANGELES
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 01
- Page No.
- 09
- Purpose
- Routine Assessment
- Project
- WO_624365_TV05272_MAR2017
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 05 0774
- Downstream MH
- 05 0773
- Dir. of Survey
- Downstream
- Length Surveyed
- 413 ft.
- Total Length
- 413 ft.
- Structural Index
- 3
- Structural Quick
- 3O21
- Structural Rating
- 242
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 242
Observation photos (4)
5 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
10 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES
13.8 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES
18.3 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 0 | AMH | 05 0774 |
| 407.9 | CM | — |
| 0 | MWL | — |
| 18.3 | CM | — |
| 10 | CM | — |
| 5 | CM | — |
| 0 | MWM | — |
| 13.8 | CL | — |
| 413 | AMH | 05 0773 |
Properties (5)
- additional_info
- SC306878
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2017-03-06T03:59:26-08:00
- sewer_category
- Gravity
