Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Aug 29, 2016, 09:42 AM

  • 22 0567_22 0566 _08292016_023347.mp4

Date
08/29/2016
W/O
592045
Weather
Dry
Operator/Surveyor
N.ZAHREDDINE
Sewer ID
Z00791
PipeID
P16913
Time
2:42 AM
Certificate
U-109-7948
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3421
Sewer Name
22 BEN LOMOND TRUNK
City
GLENDORA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
21
Purpose
Routine Assessment
Project
WO_592045_TV22006_SEP2016
Material
NRCP
Shape
Circular
Height
12 in.
Width
12 in.
Upstream MH
22 0567
Downstream MH
22 0566
Dir. of Survey
Downstream
Length Surveyed
246.1 ft.
Total Length
246.2 ft.
Structural Index
3
Structural Quick
3I00
Structural Rating
147
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
147
Pipe schematic from manhole 22 0567 to 22 0566
MH: 22 0567MH: 22 0566downstream0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 22 05670.1 ft. MWM - Water Mark, 20 %of cross sectional area2 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Start28.2 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"104.3 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"179.8 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"235.9 ft. TF - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"246.1 ft. SAV - Surface Aggregate Visible, from 07 to 05 o'clock, within 8 inches of joint: YES, Finish246.1 ft. MGO - General Observation - CONNECTION AT MH 3246.2 ft. AMH - Downstream Manhole, Survey Ends - 22 0566246.2 ft. MGO - General Observation - CONNECTION AT MH 9

Observation photos (4)

  • Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

    28.2 ft. - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

  • Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

    104.3 ft. - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

  • Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

    179.8 ft. - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"

  • Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"

    235.9 ft. - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: NO, 4"

All inspections of P16913Work order 592045

Observations (12)

DistanceCodeObservation
28.2TFC—
179.8TFC—
0MWL—
246.1SAV—
246.2AMH22 0566
0.1MWM—
246.1MGOCONNECTION AT MH 3
0AMH22 0567
2SAV—
246.2MGOCONNECTION AT MH 9
235.9TF—
104.3TFC—

Properties (5)

additional_info
SC305983
custom_field_two
3
customer
LACSD
datetime
2016-08-29T02:42:46-07:00
sewer_category
Gravity
