B 1500_B 1499 _12292016_015852.mp4
- Date
- 12/29/2016
- W/O
- 615053
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z01124
- PipeID
- P25615
- Time
- 1:36 AM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3951
- Sewer Name
- B JOINT OUTFALL B - UNIT 6G
- City
- ALHAMBRA, CA
- Loc. details
- Sidewalk
- Location Code
- F
- Use of Sewer
- Sanitary Sewer
- District
- District 16
- Page No.
- 23
- Purpose
- Routine Assessment
- Project
- WO_615053_TV16038_JAN2017
- Sewer Type
- Gravity
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 36 in.
- Width
- 36 in.
- Upstream MH
- B 1500
- Downstream MH
- B 1499
- Dir. of Survey
- Downstream
- Length Surveyed
- 607.3 ft.
- Total Length
- 607.3 ft.
- Structural Index
- 2
- Structural Quick
- 5641
- Structural Rating
- 122
- O&M Index
- 2
- O&M Quick
- 2W00
- O&M Rating
- 238
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 360
Observation photos (17)
13.1 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
20.7 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
57 ft. - Hole, from 11 to 01 o'clock, within 8 inches of joint: YES
108 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
114.1 ft. - Hole Void Visible, from 01 to 03 o'clock, within 8 inches of joint: YES
116.3 ft. - Hole Soil Visible, at 10 o'clock, within 8 inches of joint: YES
130.6 ft. - Hole Void Visible, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
203.4 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO
206.6 ft. - Hole Void Visible, at 01 o'clock, within 8 inches of joint: NO
214.9 ft. - Hole Void Visible, from 11 to 01 o'clock, within 8 inches of joint: NO
219.5 ft. - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES
248.6 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
279.5 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO, Start
282.7 ft. - Hole Soil Visible, from 12 to 03 o'clock, within 8 inches of joint: NO
553.6 ft. - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES
556.4 ft. - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
593.6 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES
Observations (28)
| Distance | Code | Observation |
|---|---|---|
| 114.1 | HVV | — |
| 605.7 | SSS | — |
| 57 | H | — |
| 248.6 | SSS | — |
| 607.3 | AMH | B 1499 |
| 13.1 | DAGS | — |
| 137 | HVV | — |
| 0 | MWL | — |
| 556.4 | SSS | — |
| 0.1 | MWM | — |
| 282.7 | HSV | — |
| 219.5 | FL | — |
| 203.4 | SSS | — |
| 0 | AMH | B 1500 |
| 206.6 | HVV | — |
| 279.5 | SSS | — |
| 130.6 | HVV | — |
| 214.9 | HVV | — |
| 116.3 | HSV | — |
| 553.6 | FL | — |
| 261.2 | SSS | — |
| 607.3 | DAGS | — |
| 20.7 | SSS | — |
| 108 | SSS | — |
| 364.6 | SSS | — |
| 26.2 | SSS | — |
| 593.6 | CL | — |
| 148.2 | SSS | — |
Properties (5)
- additional_info
- SC317699
- custom_field_two
- 1
- customer
- LACSD
- datetime
- 2016-12-29T01:36:00-08:00
- year_laid
- 38884
