Wastewater/Activity/PacpInspection/1.0Sep 28, 2016, 07:09 AM
22 1288_22 1287 _09282016_000930.mp4
- Date
- 09/28/2016
- W/O
- 591676
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00806
- PipeID
- P16484
- Time
- 12:09 AM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3720
- Sewer Name
- 22 DISTRICT #22 MAIN RELIEF TRUNK
- City
- COVINA, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 32
- Purpose
- Routine Assessment
- Project
- WO_591676_TV22107_SEP2016
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 27 in.
- Width
- 27 in.
- Upstream MH
- 22 1288
- Downstream MH
- 22 1287
- Dir. of Survey
- Downstream
- Length Surveyed
- 640.4 ft.
- Total Length
- 640.4 ft.
- Structural Index
- 2
- Structural Quick
- 2X00
- Structural Rating
- 248
- O&M Index
- 2
- O&M Quick
- 2X00
- O&M Rating
- 252
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 500
Observation photos (3)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
22.3 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
623 ft. - Water Level, Sag in pipe, 5 %of cross sectional area, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 640.2 | MGO | CONNECTION AT MH 9 ACTIVE |
| 633.8 | SSS | — |
| 623 | MWLS | — |
| 0 | MWL | — |
| 633.9 | DAGS | — |
| 0 | AMH | 22 1288 |
| 22.3 | SSS | — |
| 633.7 | MWLS | — |
| 0 | MWM | — |
| 640.4 | AMH | 22 1287 |
| 2 | MGO | MAG. H.OX START 90% |
| 640.4 | MGO | CONNECTION AT MH 3 ACTIVE |
| 2 | DAGS | — |
Properties (6)
- additional_info
- SC303707
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-09-28T00:09:00-07:00
- sewer_category
- Gravity
- year_laid
- 30238
