Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 13, 2017, 12:27 PM

  • 01 0724_01 0723_01132017_044127.mpg

Date
01/13/2017
W/O
613653
Weather
Damp
Operator/Surveyor
R.VARGAS
Sewer ID
Z00195
PipeID
P01434
Time
4:27 AM
Certificate
U-209-211
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K4078
Sewer Name
01 BULLIS ROAD RELIEF TRUNK, SECTION 1
City
LYNWOOD
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
14
Purpose
Routine Assessment
Project
WO_613653_TV01259_JAN2017
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Width
18 in.
Upstream MH
01 0724
Downstream MH
01 0723
Dir. of Survey
Downstream
Length Surveyed
328.1 ft.
Total Length
328.1 ft.
Structural Index
3
Structural Quick
3A00
Structural Rating
30
O&M Index
2
O&M Quick
2L11
O&M Rating
131
Overall Index
2
Overall Quick
—
Overall Rating
161
Pipe schematic from manhole 01 0724 to 01 0723
MH: 01 0724MH: 01 0723downstream0 ft. MWL - Water Level, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 01 07240 ft. MWM - Water Mark, 30 %of cross sectional area0 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK ACTIVE2.1 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start2.1 ft. MGO - General Observation - MAGNESIUM H.O. START141 ft. MGP - General Photograph244.4 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start291.9 ft. FL - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Finish324.7 ft. DAGS - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish324.7 ft. MGO - General Observation - MAGNEZIUM H.O. FINISH328.1 ft. VC - Vermin Cockroach328.1 ft. AMH - Downstream Manhole, Survey Ends - 01 0723

Observation photos (3)

  • Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2.1 ft. - Deposits Attached Grease, 10 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • General Photograph

    141 ft. - General Photograph

  • Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

    244.4 ft. - Fracture Longitudinal, at 12 o'clock, within 8 inches of joint: YES, Start

All inspections of P01434Work order 613653

Observations (13)

DistanceCodeObservation
2.1DAGS—
2.1MGOMAGNESIUM H.O. START
0MWL—
328.1VC—
291.9FL—
0AMH01 0724
324.7DAGS—
0MWM—
0MGOCONNECTION AT MH 3 O'CLOCK ACTIVE
328.1AMH01 0723
244.4FL—
141MGP—
324.7MGOMAGNEZIUM H.O. FINISH

Properties (5)

additional_info
SC318619
custom_field_two
3
customer
LACSD
datetime
2017-01-13T04:27:01-08:00
sewer_category
Gravity
