Wastewater/Activity/PacpInspection/1.0Nov 18, 2016, 09:24 AM
29 0470_29 0469 _11182016_012442.mp4
- Date
- 11/18/2016
- W/O
- 596943
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z01116
- PipeID
- P24516
- Time
- 1:24 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K4018
- Sewer Name
- 29 SPRING STREET SEWER
- City
- SIGNAL HILL
- Loc. details
- Main Highway - Suburban/Rural
- Location Code
- B
- Use of Sewer
- Sanitary Sewer
- District
- District 29
- Page No.
- 02
- Purpose
- Routine Assessment
- Project
- WO_596943_TV29029_NOV2016
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 29 0470
- Downstream MH
- 29 0469
- Dir. of Survey
- Downstream
- Length Surveyed
- 400.5 ft.
- Total Length
- 400.5 ft.
- Structural Index
- 2
- Structural Quick
- 2400
- Structural Rating
- 8
- O&M Index
- 2
- O&M Quick
- 2O00
- O&M Rating
- 162
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 170
Observation photos (6)
0 ft. - General Observation - COCKROACHES IN MANHOLE
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start
126.7 ft. - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: NO, 6" - MEDIUM ROOTS
231.6 ft. - Water Level, Sag in pipe, 20 %of cross sectional area, Start
389.4 ft. - Water Level, Sag in pipe, 20 %of cross sectional area, Start
400.5 ft. - General Observation - COCKROACHES IN MANHOLE
Observations (21)
| Distance | Code | Observation |
|---|---|---|
| 240 | MWLS | — |
| 269.7 | TFA | — |
| 389.4 | MWLS | — |
| 0 | MWL | — |
| 13.4 | TB | — |
| 0 | MWM | — |
| 282.1 | TF | — |
| 199.6 | TFA | — |
| 2 | DAGS | — |
| 119.6 | TF | — |
| 126.7 | TFD | MEDIUM ROOTS |
| 374.6 | TF | — |
| 400.5 | MGO | COCKROACHES IN MANHOLE |
| 0 | MGO | CAPPED CONNECTION AT MH 9 O'CLOCK |
| 231.6 | MWLS | — |
| 0 | AMH | 29 0470 |
| 201.9 | TF | — |
| 398.1 | MWLS | — |
| 400.5 | DAGS | — |
| 0 | MGO | COCKROACHES IN MANHOLE |
| 400.5 | AMH | 29 0469 |
Properties (5)
- additional_info
- SC306410
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-11-18T01:24:24-08:00
- sewer_category
- Gravity
