Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 2, 2016, 06:38 AM

  • 02 0109_02 0109_110216_000819.mp4

Date
11/01/2016
W/O
602602
Weather
Dry
Operator/Surveyor
J. HARTOOG
Sewer ID
Z00237
PipeID
P02276
Time
11:38 PM
Certificate
U-507-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K3754
Sewer Name
02 BELLFLOWER TRUNK
City
BELLFLOWER, CA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
38
Purpose
Routine Assessment
Project
WO_602602_TV02019_NOV2016
Sewer Type
Gravity
Material
Vitrified Clay Pipe
Shape
Circular
Height
10 in.
Width
10 in.
Upstream MH
02 0109
Downstream MH
02 0108
Dir. of Survey
Downstream
Length Surveyed
324.9 ft.
Total Length
324.9 ft.
Structural Index
2
Structural Quick
3223
Structural Rating
12
O&M Index
2
O&M Quick
312L
O&M Rating
131
Overall Index
2
Overall Quick
—
Overall Rating
143
Pipe schematic from manhole 02 0109 to 02 0108
MH: 02 0109MH: 02 0108downstream0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 02 01090 ft. MWL - Water Level, 10 %of cross sectional area1.6 ft. FL - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: NO4.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: NO, Start47.4 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 4"71.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"72.4 ft. CL - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO94.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"97.5 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 4"118.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"144.9 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"147.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 4"171.6 ft. TF - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: NO, 4"172.5 ft. CL - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES194.6 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"197.8 ft. TFI - Tap Factory Made Intruding, at 10 o'clock, -, -, within 8 inches of joint: NO, 4", 3"221.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"245.4 ft. TFC - Tap Factory Made Capped, at 02 o'clock, -, within 8 inches of joint: NO, 4"248.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"277.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 4"308.9 ft. CM - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES318.1 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES324 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: NO, Finish324.9 ft. AMH - Downstream Manhole, Survey Ends - 02 0108

Observation photos (6)

  • Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: NO

    1.6 ft. - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: NO

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: NO, Start

    4.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: NO, Start

  • Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO

    72.4 ft. - Crack Longitudinal, at 02 o'clock, within 8 inches of joint: NO

  • Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

    172.5 ft. - Crack Longitudinal, at 12 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

    308.9 ft. - Crack Multiple, from 10 to 02 o'clock, within 8 inches of joint: YES

  • Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES

    318.1 ft. - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES

All inspections of P02276Work order 602602

Observations (25)

DistanceCodeObservation
318.1FC—
194.6TFC—
172.5CL—
0MWM—
245.4TFC—
308.9CM—
1.6FL—
47.4TFA—
0AMH02 0109
171.6TF—
324.9AMH02 0108
221.6TFC—
277.7TFC—
72.4CL—
0MWL—
147.6TF—
197.8TFI—
248.1TFC—
71.2TFC—
324DAGS—
97.5TF—
94.9TFC—
144.9TFC—
118.1TFC—
4.5DAGS—

Properties (4)

additional_info
SC303746
custom_field_two
2
customer
LACSD
datetime
2016-11-01T23:38:00-07:00
