Wastewater/Activity/PacpInspection/1.0Dec 1, 2016, 07:09 AM
02 1443_02 1442_11302016_231904.mp4
- Date
- 11/30/2016
- W/O
- 602592
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00307
- PipeID
- P04683
- Time
- 11:09 PM
- Certificate
- U-507-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3928
- Sewer Name
- 02 TRACT #5445 TRUNK
- City
- LOS ANGELES, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 13
- Purpose
- Routine Assessment
- Project
- WO_602592_TV02117_NOV2016
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Width
- 18 in.
- Upstream MH
- 02 1443
- Downstream MH
- 02 1442
- Dir. of Survey
- Downstream
- Length Surveyed
- 333.8 ft.
- Total Length
- 333.8 ft.
- Structural Index
- 2
- Structural Quick
- 2111
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 5
Observation photos (3)
3.2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
93 ft. - Fracture Circumferential, from 07 to 11 o'clock, within 8 inches of joint: YES
113.1 ft. - Crack Circumferential, from 07 to 09 o'clock, within 8 inches of joint: YES
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 3.2 | DAGS | — |
| 0 | MWM | — |
| 333.8 | AMH | 02 1442 |
| 113.1 | CC | — |
| 0 | MWL | — |
| 43.3 | TF | — |
| 0 | AMH | 02 1443 |
| 93 | FC | — |
| 331.2 | DAGS | — |
Properties (5)
- additional_info
- SC317672
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-11-30T23:09:00-08:00
- sewer_category
- Gravity
