Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 4, 2016, 07:12 AM

  • 02 1139_02 1138_11042016_001243.mp4

Date
11/04/2016
W/O
602268
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00351
PipeID
P02922
Time
12:12 AM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3907
Sewer Name
02 GARFIELD AVENUE EXTENSION TRUNK
City
MONTEBELLO
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
13
Purpose
Routine Assessment
Project
WO_602268_TV02061_NOV2016
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Width
15 in.
Upstream MH
02 1139
Downstream MH
02 1138
Dir. of Survey
Downstream
Length Surveyed
304 ft.
Total Length
304 ft.
Structural Index
3
Structural Quick
3J00
Structural Rating
171
O&M Index
2
O&M Quick
312K
O&M Rating
125
Overall Index
2
Overall Quick
—
Overall Rating
296
Pipe schematic from manhole 02 1139 to 02 1138
MH: 02 1139MH: 02 1138downstream0 ft. MWL - Water Level, 20 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 02 11390 ft. MGO - General Observation - COCKROACHES IN MANHOLE0 ft. MWM - Water Mark, 25 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start15.2 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"16.8 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start83.1 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"130.7 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"178.2 ft. TFD - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: NO, 6" - SEVERE ROOTS178.2 ft. RML - Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES225.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"269.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"288.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"302 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish302 ft. MGO - General Observation - COCKROACHES IN MANHOLE302 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish304 ft. AMH - Downstream Manhole, Survey Ends - 02 1138304 ft. MGO - General Observation - CONNECTION AT MH 3 O'CLOCK

Observation photos (6)

  • General Observation - COCKROACHES IN MANHOLE

    0 ft. - General Observation - COCKROACHES IN MANHOLE

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    16.8 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: NO, 6" - SEVERE ROOTS

    178.2 ft. - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: NO, 6" - SEVERE ROOTS

  • Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES

    178.2 ft. - Roots Medium Lateral, from 09 to 11 o'clock, 10 %, within 8 inches of joint: YES

  • General Observation - COCKROACHES IN MANHOLE

    302 ft. - General Observation - COCKROACHES IN MANHOLE

All inspections of P02922Work order 602268

Observations (19)

DistanceCodeObservation
304AMH02 1138
0MWL—
302DAGS—
0AMH02 1139
2DAGS—
0MGOCOCKROACHES IN MANHOLE
16.8CM—
83.1TFC—
178.2TFDSEVERE ROOTS
15.2TFC—
0MWM—
269.4TFC—
304MGOCONNECTION AT MH 3 O'CLOCK
288.4TFC—
302MGOCOCKROACHES IN MANHOLE
130.7TFC—
302CM—
225.8TFC—
178.2RML—

Properties (5)

additional_info
SC306345
custom_field_two
3
customer
LACSD
datetime
2016-11-04T00:12:03-07:00
sewer_category
Gravity
