Wastewater/Activity/PacpInspection/1.0Feb 12, 2016, 07:46 AM
17 0069_17 0068_11022016_234657.mp4
- Date
- 02/11/2016
- W/O
- 552349
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00668
- PipeID
- P13788
- Time
- 11:46 PM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3256
- Sewer Name
- 17 DISTRICT #17 MAIN TRUNK
- City
- ALTADENA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 17
- Page No.
- 04
- Purpose
- Routine Assessment
- Project
- WO_552349_TV17005_FEB2016
- Material
- NRCP
- Shape
- Other
- Height
- 15 in.
- Upstream MH
- 17 0069
- Downstream MH
- 17 0068
- Dir. of Survey
- Downstream
- Length Surveyed
- 275.5 ft.
- Total Length
- 275.5 ft.
- Structural Index
- 3
- Structural Quick
- 3J00
- Structural Rating
- 162
- O&M Index
- 2
- O&M Quick
- 2J00
- O&M Rating
- 110
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 272
Observation photos (4)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
2.3 ft. - General Observation - MAG COATING 80%
2.3 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
259.8 ft. - Tap Factory Made Defective, at 10 o'clock, -, within 8 inches of joint: NO, 6" - ROOTS
Observations (18)
| Distance | Code | Observation |
|---|---|---|
| 275.5 | AMH | 17 0068 |
| 0 | MWM | — |
| 2 | DAGS | — |
| 61.6 | TFA | — |
| 43 | TFC | — |
| 149.9 | TBA | — |
| 0 | MWL | — |
| 259.8 | TFD | ROOTS |
| 273.3 | SAV | — |
| 49.2 | TFA | — |
| 2.3 | MGO | MAG COATING 80% |
| 273.3 | DAGS | — |
| 0 | AMH | 17 0069 |
| 0 | MGO | ACTIVE CONNECTION AT MH 9 O'CLOCK |
| 198.6 | TFA | — |
| 174.3 | TFA | — |
| 2.3 | SAV | — |
| 146.9 | TFC | — |
Properties (5)
- additional_info
- SC225478
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-02-11T23:46:36-08:00
- sewer_category
- GRAVITY
