Wastewater/Activity/PacpInspection/1.0Sep 1, 2016, 11:10 AM
05 1523_05 1522 _09012016_041211.mp4
- Date
- 09/01/2016
- W/O
- 585661
- Weather
- Dry
- Operator/Surveyor
- S. LOPEZ
- Sewer ID
- Z00528
- PipeID
- P06745
- Time
- 4:10 AM
- Certificate
- U-111-11880
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3651
- Sewer Name
- 05 TORRANCE EXTENSION TRUNK
- City
- TORRANCE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 29
- Purpose
- Routine Assessment
- Project
- WO_585661_TV05309_AUG2016
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Width
- 8 in.
- Upstream MH
- 05 1523
- Downstream MH
- 05 1522
- Dir. of Survey
- Downstream
- Length Surveyed
- 307.5 ft.
- Total Length
- 307.5 ft.
- Structural Index
- 3
- Structural Quick
- 413J
- Structural Rating
- 172
- O&M Index
- 2
- O&M Quick
- 2K00
- O&M Rating
- 122
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 294
Observation photos (3)
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
27.4 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
222.1 ft. - Fracture Multiple, from 12 to 12 o'clock, within 8 inches of joint: YES
Observations (18)
| Distance | Code | Observation |
|---|---|---|
| 0 | MWL | — |
| 305.4 | DAGS | — |
| 222.1 | FM | — |
| 126.4 | TFA | — |
| 196.8 | TF | — |
| 80.3 | TF | — |
| 305.4 | CM | — |
| 307.5 | AMH | 05 1522 |
| 307.5 | MGO | ACTIVE CONNECTION AT MH 9 O'CLOCK |
| 2 | DAGS | — |
| 0 | MWM | — |
| 291.1 | TFC | — |
| 0 | AMH | 05 1523 |
| 50.1 | TF | — |
| 160.3 | TF | — |
| 5.2 | TF | — |
| 214.8 | TF | — |
| 27.4 | CM | — |
Properties (5)
- additional_info
- SC306091
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-09-01T04:10:50-07:00
- sewer_category
- Gravity
