Wastewater/Activity/PacpInspection/1.0Aug 2, 2016, 07:38 AM
02 1479_02 1478 _20160802_014516.mp4
- Date
- 08/02/2016
- W/O
- 585991
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00309
- PipeID
- P03923
- Time
- 12:38 AM
- Certificate
- 507-03-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3670
- Sewer Name
- 02 UNION PACIFIC TRUNK
- City
- COMMERCE, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 16
- Purpose
- Routine Assessment
- Project
- WO_585991_TV02189_AUG2016
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 02 1478
- Downstream MH
- 02 1479
- Dir. of Survey
- Upstream
- Length Surveyed
- 236.7 ft.
- Total Length
- 236.7 ft.
- Structural Index
- 2
- Structural Quick
- 2100
- Structural Rating
- 2
- O&M Index
- 2
- O&M Quick
- 2200
- O&M Rating
- 4
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 6
Observation photos (4)
0 ft. - General Observation - CONNECTION AT THE MH 9 O'CLOCK ACTIVE
42.4 ft. - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 4"
52.9 ft. - Deposits Settled Gravel, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start
114.6 ft. - Tap Factory Made, at 10 o'clock, -, within 8 inches of joint: YES, 4"
Observations (15)
| Distance | Code | Observation |
|---|---|---|
| 142.1 | TFC | — |
| 236.7 | AMH | 02 1479 |
| 74.2 | DSGV | — |
| 0 | AMH | 02 1478 |
| 42.4 | TF | — |
| 5.4 | DAGS | — |
| 165.9 | TFC | — |
| 235.6 | DAGS | — |
| 0 | MWM | — |
| 114.6 | TF | — |
| 52.9 | DSGV | — |
| 192.8 | CL | — |
| 192.8 | TF | — |
| 0 | MWL | — |
| 0 | MGO | CONNECTION AT THE MH 9 O'CLOCK ACTIVE |
Properties (5)
- additional_info
- SC305550
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-08-02T00:38:00-07:00
- sewer_category
- Gravity
