Wastewater/Activity/PacpInspection/1.0Aug 2, 2016, 06:22 AM
02 1476_02 1475 _20160802_003318.mp4
- Date
- 08/01/2016
- W/O
- 585991
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z00309
- PipeID
- P03920
- Time
- 11:22 PM
- Certificate
- 507-03-3386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K3670
- Sewer Name
- 02 UNION PACIFIC TRUNK
- City
- COMMERCE, CA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 16
- Purpose
- Routine Assessment
- Project
- WO_585991_TV02189_AUG2016
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 15 in.
- Width
- 15 in.
- Upstream MH
- 02 1476
- Downstream MH
- 02 1475
- Dir. of Survey
- Downstream
- Length Surveyed
- 269 ft.
- Total Length
- 269 ft.
- Structural Index
- 2
- Structural Quick
- 3123
- Structural Rating
- 11
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 13
Observation photos (5)
0 ft. - General Observation - CONNECTION AT THE MH 3 O'CLOCK ACTIVE
0.1 ft. - General Observation - CONNECTION AT THE MH 9 O'CLOCK ACTIVE
3.6 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
186.1 ft. - Tap Factory Made, at 02 o'clock, -, within 8 inches of joint: YES, 4"
208.7 ft. - Crack Circumferential, from 06 to 09 o'clock, within 8 inches of joint: YES
Observations (21)
| Distance | Code | Observation |
|---|---|---|
| 222.6 | TFC | — |
| 6 | CL | — |
| 263 | CC | — |
| 265.3 | DAGS | — |
| 208.7 | CC | — |
| 0 | MWL | — |
| 175.8 | CL | — |
| 0 | AMH | 02 1476 |
| 108.3 | TFC | — |
| 3.6 | DAGS | — |
| 269 | MGO | CONNECTION AT THE MH 3 O'CLOCK ACTIVE |
| 84.5 | TFC | — |
| 159.4 | TFC | — |
| 0 | MWM | — |
| 0.1 | MGO | CONNECTION AT THE MH 9 O'CLOCK ACTIVE |
| 186.1 | TF | — |
| 269 | AMH | 02 1475 |
| 85.1 | CL | — |
| 135.1 | TFC | — |
| 36.3 | CM | — |
| 0 | MGO | CONNECTION AT THE MH 3 O'CLOCK ACTIVE |
Properties (5)
- additional_info
- SC305550
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-08-01T23:22:00-07:00
- sewer_category
- Gravity
