Wastewater/Activity/PacpInspection/1.0May 6, 2016, 10:15 AM
29 0005_29 0004_06052016_031540.mp4
- Date
- 05/06/2016
- W/O
- 568954
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00849
- PipeID
- P17679
- Time
- 3:15 AM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3367
- Sewer Name
- 29 SIGNAL HILL OUTFALL TRUNK
- City
- LONG BEACH
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 03
- Page No.
- 19
- Purpose
- Routine Assessment
- Project
- RFIR_WO_568954_TV29096_MAY2016
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 24 in.
- Upstream MH
- 29 0005
- Downstream MH
- 29 0004
- Dir. of Survey
- Downstream
- Length Surveyed
- 91.4 ft.
- Total Length
- 91.4 ft.
- Structural Index
- 4
- Structural Quick
- 5131
- Structural Rating
- 8
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 3
- Overall Quick
- —
- Overall Rating
- 10
Observation photos (4)
2.6 ft. - Surface Aggregate Projecting, from 09 to 03 o'clock, within 8 inches of joint: YES, Start
8.8 ft. - Infiltration Stain, from 09 to 10 o'clock, within 8 inches of joint: YES
17.7 ft. - Surface Reinforcement Visible, from 12 to 02 o'clock, within 8 inches of joint: NO, Start
65.5 ft. - Deposits Attached Encrustation, 5 %of cross sectional area, from 01 to 04 o'clock, , within 8 inches of joint: YES
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 17.7 | SRV | — |
| 91.4 | MGO | INFILTRATION AT MH |
| 91.4 | AMH | 29 0004 |
| 0 | AMH | 29 0005 |
| 65.5 | DAE | — |
| 0 | MWL | — |
| 2.6 | SAP | — |
| 88.7 | SAP | — |
| 0 | MWM | — |
| 88.7 | SRV | — |
| 8.8 | IS | — |
Properties (5)
- additional_info
- SC300363
- custom_field_two
- 2
- customer
- LACSD
- datetime
- 2016-05-06T03:15:26-07:00
- sewer_category
- GRAVITY
