Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 10, 2016, 06:16 AM

  • 01 1287_01 1286_09032016_221755.mp4

Date
03/09/2016
W/O
557557
Weather
Dry
Operator/Surveyor
S. LOPEZ
Sewer ID
Z00207
PipeID
P01583
Time
10:16 PM
Certificate
U-111-11880
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K3281
Sewer Name
01 CROCKETT BOULEVARD-GLEN AVENUE RELIEF TRUNK
City
LOS ANGELES
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
13
Purpose
Routine Assessment
Project
WO_557557_TV01128_2016MAR
Material
Vitrified Clay Pipe
Shape
Circular
Height
21 in.
Upstream MH
01 1287
Downstream MH
01 1286
Dir. of Survey
Downstream
Length Surveyed
567.2 ft.
Total Length
567.2 ft.
Structural Index
5
Structural Quick
5100
Structural Rating
5
O&M Index
2
O&M Quick
2V00
O&M Rating
226
Overall Index
2
Overall Quick
—
Overall Rating
231
Pipe schematic from manhole 01 1287 to 01 1286
MH: 01 1287MH: 01 1286downstream0 ft. AMH - Upstream Manhole, Survey Begins - 01 12870 ft. MWM - Water Mark, 25 %of cross sectional area0 ft. MWL - Water Level, 25 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start5.7 ft. B - Broken, from 08 to 03 o'clock, within 8 inches of joint: YES6.9 ft. TBA - Tap Break-In Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"15.2 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"73.6 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: NO, 6"189.2 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"192.2 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"240.2 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"243.7 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"288.5 ft. TFA - Tap Factory Made Active, at 01 o'clock, -, within 8 inches of joint: NO, 6"315.1 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"338.9 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"348 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"372.4 ft. TBA - Tap Break-In Active, at 01 o'clock, -, within 8 inches of joint: NO, 6"410 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"438.3 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"450.5 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"471.6 ft. TBA - Tap Break-In Active, at 12 o'clock, -, within 8 inches of joint: NO, 6"498.9 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"522.6 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"552 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"565.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Finish565.6 ft. MGO - General Observation - COCKROACHES IN MANHOLE567.2 ft. AMH - Downstream Manhole, Survey Ends - 01 1286

Observation photos (2)

  • Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start

  • Broken, from 08 to 03 o'clock, within 8 inches of joint: YES

    5.7 ft. - Broken, from 08 to 03 o'clock, within 8 inches of joint: YES

All inspections of P01583Work order 557557

Observations (27)

DistanceCodeObservation
471.6TBA—
438.3TFA—
410TFA—
73.6TFC—
315.1TFA—
189.2TFA—
2DAGS—
565.6DAGS—
240.2TFA—
372.4TBA—
348TFA—
565.6MGOCOCKROACHES IN MANHOLE
0AMH01 1287
192.2TFA—
450.5TFA—
552TFA—
5.7B—
243.7TFA—
338.9TFA—
498.9TFA—
15.2TFA—
0MWM—
0MWL—
6.9TBA—
567.2AMH01 1286
522.6TFA—
288.5TFA—

Properties (5)

additional_info
SC305405
custom_field_two
2
customer
LACSD
datetime
2016-03-09T22:16:44-08:00
sewer_category
GRAVITY
