Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 8, 2016, 09:07 AM

  • 02 0915_02 0914_20160108_011555_.mp4

Date
01/08/2016
W/O
546949
Weather
Dry
Operator/Surveyor
N.ZAHREDDINE
Sewer ID
Z00252
PipeID
P03483
Time
1:07 AM
Certificate
U-109-7948
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K2951
Sewer Name
02 DOWNEY-BELLFLOWER DIVERSION TRUNK
City
DOWNEY
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
24
Purpose
Routine Assessment
Project
WO_546949_TV02053_JAN2016
Material
Vitrified Clay Pipe
Shape
Circular
Height
24 in.
Upstream MH
02 0915
Downstream MH
02 0914
Dir. of Survey
Downstream
Length Surveyed
120.2 ft.
Total Length
120.2 ft.
Structural Index
3
Structural Quick
4121
Structural Rating
6
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
3
Overall Quick
—
Overall Rating
10
Pipe schematic from manhole 02 0915 to 02 0914
MH: 02 0915MH: 02 0914downstream0 ft. MWL - Water Level, 30 %of cross sectional area0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 02 09154.6 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES46 ft. CL - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES120.2 ft. AMH - Downstream Manhole, Survey Ends - 02 0914

Observation photos (2)

  • Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

    4.6 ft. - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES

  • Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

    46 ft. - Crack Longitudinal, at 09 o'clock, within 8 inches of joint: YES

All inspections of P03483Work order 546949

Observations (6)

DistanceCodeObservation
0MWL—
46CL—
4.6FM—
0MWM—
0AMH02 0915
120.2AMH02 0914

Properties (5)

additional_info
SC224962
custom_field_two
3
customer
LACSD
datetime
2016-01-08T01:07:02-08:00
sewer_category
GRAVITY
