Wastewater/Activity/PacpInspection/1.0Dec 17, 2015, 11:13 AM
H 1064_A 0634_20151217_034210.mp4
- Date
- 12/17/2015
- W/O
- 541844
- Weather
- Dry
- Operator/Surveyor
- R.VARGAS
- Sewer ID
- Z00316
- PipeID
- P07840
- Time
- 3:13 AM
- Certificate
- U-209-211
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K3012
- Sewer Name
- A JOA-1A DISTRICT 21 INTERCEPTOR
- City
- CITY OF INDUSTRY
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 21
- Page No.
- 34
- Purpose
- Routine Assessment
- Project
- WO_541844_TV21027_DEC2015
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 42 in.
- Upstream MH
- H 1064
- Downstream MH
- A 0634
- Dir. of Survey
- Downstream
- Length Surveyed
- 972.9 ft.
- Total Length
- 972.9 ft.
- Structural Index
- 3
- Structural Quick
- 3100
- Structural Rating
- 3
- O&M Index
- 2
- O&M Quick
- 2111
- O&M Rating
- 3
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 6
Observation photos (3)
2.9 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 04 to 08 o'clock, , within 8 inches of joint: YES, Start
2.9 ft. - General Observation - MAGNESIUM H.O. START
2.9 ft. - Surface Aggregate Projecting, from 08 to 04 o'clock, within 8 inches of joint: YES, Start
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 966.4 | SAP | — |
| 2.9 | DAGS | — |
| 2.9 | MGO | MAGNESIUM H.O. START |
| 0 | MWM | — |
| 0 | AMH | H 1064 |
| 0 | MGO | BULKHEAD AT MH |
| 972.9 | AMH | A 0634 |
| 29.8 | VC | — |
| 965.9 | MGO | MAGNESIUM H.O. FINISH |
| 2.9 | SAP | — |
| 966.3 | DAGS | — |
| 855 | TFA | — |
| 0 | MWL | — |
Properties (5)
- additional_info
- SC224605
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2015-12-17T03:13:35-08:00
- sewer_category
- GRAVITY
