Wastewater/Activity/PacpInspection/1.0Jan 28, 2016, 06:38 AM
05 0143_05 0142_20160127_224631.mp4
- Date
- 01/27/2016
- W/O
- 541742
- Weather
- Dry
- Operator/Surveyor
- B.FUGATE
- Sewer ID
- Z00431
- PipeID
- P05435
- Time
- 10:38 PM
- Certificate
- U-508-7069
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- No Pre-Cleaning
- Media Label
- K2784
- Sewer Name
- 05 DISTRICT #5 MAIN TRUNK
- City
- HAWTHORNE
- Loc. details
- Main Highway - Urban
- Location Code
- A
- Use of Sewer
- Sanitary Sewer
- District
- District 05
- Page No.
- 13
- Purpose
- Routine Assessment
- Project
- WO_541742_TV05147_DEC2015
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 33 in.
- Upstream MH
- 05 0143
- Downstream MH
- 05 0142
- Dir. of Survey
- Downstream
- Length Surveyed
- 177.9 ft.
- Total Length
- 177.9 ft.
- Structural Index
- 2
- Structural Quick
- 2200
- Structural Rating
- 4
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 4
Observation photos (3)
2.5 ft. - General Observation - MAG COAT
4.1 ft. - Surface Spalling, from 10 to 04 o'clock, within 8 inches of joint: NO
38.8 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: NO, Start
Observations (11)
| Distance | Code | Observation |
|---|---|---|
| 176.1 | SSS | — |
| 2.5 | MGO | MAG COAT |
| 177.9 | MGO | LATERAL AT MH 12 OCLOCK CAPPED |
| 0 | MWM | — |
| 4.1 | SSS | — |
| 38.8 | SSS | — |
| 0 | MGO | LATERAL AT MH 3 OCLOCK |
| 177.9 | MGO | LATERAL AT MH 3 OCLOCK |
| 0 | MWL | — |
| 177.9 | AMH | 05 0142 |
| 0 | AMH | 05 0143 |
Properties (4)
- additional_info
- SC207096
- custom_field_two
- 3
- customer
- LACSD
- datetime
- 2016-01-27T22:38:34-08:00
