Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Jan 26, 2016, 08:57 AM

  • 05 1687_05 1686_20160126_010256.mp4

Date
01/26/2016
W/O
541735
Weather
Dry
Operator/Surveyor
B.FUGATE
Sewer ID
Z00471
PipeID
P06916
Time
12:57 AM
Certificate
U-508-7069
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K2781
Sewer Name
05 LOMITA TRUNK
City
LOMITA
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 08
Page No.
16
Purpose
Routine Assessment
Project
WO_541735_TV05197_DEC2015
Material
Vitrified Clay Pipe
Shape
Circular
Height
15 in.
Upstream MH
05 1687
Downstream MH
05 1686
Dir. of Survey
Downstream
Length Surveyed
65.8 ft.
Total Length
65.8 ft.
Structural Index
3
Structural Quick
3300
Structural Rating
9
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
9
Pipe schematic from manhole 05 1687 to 05 1686
MH: 05 1687MH: 05 1686downstream0 ft. AMH - Upstream Manhole, Survey Begins - 05 16870 ft. MWL - Water Level, 10 %of cross sectional area0 ft. MWM - Water Mark, 15 %of cross sectional area0.1 ft. MGO - General Observation - LATERAL AT MH 9 OCLOCK0.1 ft. MGO - General Observation - LATERAL AT MH 3 OCLOCK2.1 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES5.8 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES8.3 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start64.9 ft. CM - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish65.8 ft. AMH - Downstream Manhole, Survey Ends - 05 1686

Observation photos (3)

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    2.1 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

    5.8 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES

  • Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    8.3 ft. - Crack Multiple, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

All inspections of P06916Work order 541735

Observations (10)

DistanceCodeObservation
5.8CM—
8.3CM—
0AMH05 1687
64.9CM—
0.1MGOLATERAL AT MH 9 OCLOCK
0MWL—
2.1CM—
65.8AMH05 1686
0MWM—
0.1MGOLATERAL AT MH 3 OCLOCK

Properties (5)

additional_info
SC207093
custom_field_three
CRACKS
custom_field_two
3
customer
LACSD
datetime
2016-01-26T00:57:03-08:00
