Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 3, 2015, 12:29 PM

  • 30 0154_30 0153_20151130_054614_.mp4

Date
12/03/2015
W/O
536532
Weather
Dry
Operator/Surveyor
M.MARTINEZ
Sewer ID
Z00878
PipeID
P17859
Time
4:29 AM
Certificate
12345
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
No Pre-Cleaning
Media Label
K2917
Sewer Name
30 SOUTH BAY CITIES MAIN TRUNK
City
REDONDO BEACH
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 30
Page No.
07
Purpose
Routine Assessment
Project
WO_536532_TV30036_NOV2015
Material
Vitrified Clay Pipe
Shape
Other
Height
10 in.
Upstream MH
30 0154
Downstream MH
30 0153
Dir. of Survey
Downstream
Length Surveyed
52.2 ft.
Total Length
52.2 ft.
Structural Index
1
Structural Quick
1100
Structural Rating
1
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
1
Overall Quick
—
Overall Rating
1
Pipe schematic from manhole 30 0154 to 30 0153
MH: 30 0154MH: 30 0153downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 30 01540 ft. MWM - Water Mark, 30 %of cross sectional area40.7 ft. CC - Crack Circumferential, from 01 to 05 o'clock, within 8 inches of joint: YES51.6 ft. MGO - General Observation - CONNECTION AT THE MH 3 O'CLOCK52.2 ft. AMH - Downstream Manhole, Survey Ends - 30 0153

Observation photos (2)

  • Crack Circumferential, from 01 to 05 o'clock, within 8 inches of joint: YES

    40.7 ft. - Crack Circumferential, from 01 to 05 o'clock, within 8 inches of joint: YES

  • General Observation - CONNECTION AT THE MH 3 O'CLOCK

    51.6 ft. - General Observation - CONNECTION AT THE MH 3 O'CLOCK

All inspections of P17859Work order 536532

Observations (6)

DistanceCodeObservation
0MWL—
40.7CC—
51.6MGOCONNECTION AT THE MH 3 O'CLOCK
0AMH30 0154
0MWM—
52.2AMH30 0153

Properties (5)

additional_info
SC205550
custom_field_two
4
customer
LACSD
datetime
2015-12-03T04:29:54-08:00
sewer_category
GRAVITY
