Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 22, 2015, 11:52 AM

  • H 1269_H 1268_20151222_040841.mp4

Date
12/22/2015
W/O
536444
Weather
Heavy Rain
Operator/Surveyor
J. HARTOOG
Sewer ID
Z01181
PipeID
P17194
Time
3:52 AM
Certificate
U-507-03-3386
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
K2896
Sewer Name
H JOINT OUTFALL H - UNIT 8K
City
COVINA, CA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 22
Page No.
19
Purpose
Routine Assessment
Project
WO_536444_TV22032_DEC2015
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Upstream MH
H 1269
Downstream MH
H 1268
Dir. of Survey
Downstream
Length Surveyed
449.3 ft.
Total Length
449.3 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
3111
O&M Rating
4
Overall Index
2
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole H 1269 to H 1268
MH: H 1269MH: H 1268downstream0 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - H 12692 ft. MGO - General Observation - BEGIN MAGNESIUM HYDROXIDE COATING49.2 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"66.8 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 6"121.4 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 6"130.6 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: NO, 6"195.7 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 6"225.9 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"233.9 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"267 ft. RMC - Roots Medium Connection, from 08 to 10 o'clock, 5 %, within 8 inches of joint: YES267.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"315.3 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: YES, 6"330.8 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"371.1 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"393.2 ft. VC - Vermin Cockroach426.5 ft. TFA - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"434.7 ft. TFA - Tap Factory Made Active, at 02 o'clock, -, within 8 inches of joint: NO, 6"445.6 ft. MGO - General Observation - END OF MAG HYDROXIDE COATING449.3 ft. AMH - Downstream Manhole, Survey Ends - H 1268

Observation photos (1)

  • Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"

    267.1 ft. - Tap Factory Made Active, at 10 o'clock, -, within 8 inches of joint: YES, 6"

All inspections of P17194Work order 536444

Observations (21)

DistanceCodeObservation
426.5TFA—
2MGOBEGIN MAGNESIUM HYDROXIDE COATING
195.7TFA—
267RMC—
315.3TFA—
0MWM—
371.1TFA—
66.8TFA—
49.2TFA—
267.1TFA—
445.6MGOEND OF MAG HYDROXIDE COATING
330.8TFA—
0MWL—
233.9TFA—
449.3AMHH 1268
0AMHH 1269
225.9TFA—
130.6TFA—
393.2VC—
434.7TFA—
121.4TFA—

Properties (5)

additional_info
SC224474
custom_field_two
4
customer
LACSD
datetime
2015-12-22T03:52:00-08:00
sewer_category
GRAVITY
