Wastewater/Activity/PacpInspection/1.0Jan 5, 2016, 11:59 AM
H 1512_H 1513_20160105_040617.mp4
- Date
- 01/05/2016
- W/O
- 536417
- Weather
- Dry
- Operator/Surveyor
- J. HARTOOG
- Sewer ID
- Z01206
- PipeID
- P25959
- Time
- 3:59 AM
- Certificate
- U507033386
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- K2904
- Sewer Name
- H JOINT OUTFALL H - UNIT 8M RELIEF
- City
- W. COVINA
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 22
- Page No.
- 31
- Purpose
- Routine Assessment
- Project
- WO_536417_TV22149_NOV2015
- Material
- Reinforced Concrete Pipe
- Shape
- Circular
- Height
- 27 in.
- Upstream MH
- H 1512
- Downstream MH
- H 1513
- Dir. of Survey
- Downstream
- Length Surveyed
- 61.1 ft.
- Total Length
- 61.1 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2A00
- O&M Rating
- 22
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 22
Observation photos (4)
0 ft. - General Observation - CONNECTION AT MANHOLE ACTIVE 3 O'CLOCK
2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start
2 ft. - General Observation - BEGIN MAGNESIUM HYDROXIDE COATING
55.3 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish
Observations (9)
| Distance | Code | Observation |
|---|---|---|
| 0 | MGO | CONNECTION AT MANHOLE ACTIVE 3 O'CLOCK |
| 0 | MWL | — |
| 61.1 | AMH | H 1513 |
| 61.1 | MGO | CONNECTION AT MANHOLE ACTIVE 3 O'CLOCK |
| 2 | DAGS | — |
| 55.3 | DAGS | — |
| 2 | MGO | BEGIN MAGNESIUM HYDROXIDE COATING |
| 0 | AMH | H 1512 |
| 0 | MWM | — |
Properties (6)
- additional_info
- SC224483
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-01-05T03:59:00-08:00
- sewer_category
- GRAVITY
- year_laid
- 19820406
