Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Apr 18, 2017, 03:27 PM

  • A 0533_A 0532_4182017_093702.mp4

Date
04/18/2017
W/O
0618889
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00315
PipeID
P07769
Time
8:27 AM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7384
Sewer Name
A JOA-1A DISTRICT 5 INTERCEPTOR
City
GARDENA
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
20
Purpose
Routine Assessment
Project
20170413DF_JOA_1A_DISTRICT_5_INTERCEPTOR
Material
Reinforced Concrete Pipe
Shape
Circular
Height
54 in.
Upstream MH
A 0533
Downstream MH
A 0532
Dir. of Survey
Downstream
Length Surveyed
669.1 ft.
Total Length
669.1 ft.
Structural Index
3
Structural Quick
3121
Structural Rating
5
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
3
Overall Quick
—
Overall Rating
5
Pipe schematic from manhole A 0533 to A 0532
MH: A 0533MH: A 0532downstream0 ft. MWM - Water Mark, 35 %of cross sectional area0 ft. MWL - Water Level, 30 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 8:30 AM0.1 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start0.1 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start272.4 ft. MGP - General Photograph - PEELING/FLAKING355.5 ft. MGP - General Photograph - PEELING/FLAKING487.6 ft. MGP - General Photograph - RAGS534.1 ft. MGP - General Photograph - AGGREGATE642.2 ft. MGP - General Photograph - PEELING/FLAKING668.1 ft. SAV - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish668.1 ft. SSS - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Finish668.6 ft. MGO - General Observation - Conn. @ Mh, 3 O' Clock. Active669.1 ft. AMH - Downstream Manhole, Survey Ends - 10:22 AM

Observation photos (7)

  • Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    0.1 ft. - Surface Aggregate Visible, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

    0.1 ft. - Surface Spalling, from 08 to 04 o'clock, within 8 inches of joint: YES, Start

  • General Photograph - PEELING/FLAKING

    272.4 ft. - General Photograph - PEELING/FLAKING

  • General Photograph - PEELING/FLAKING

    355.5 ft. - General Photograph - PEELING/FLAKING

  • General Photograph - RAGS

    487.6 ft. - General Photograph - RAGS

  • General Photograph - AGGREGATE

    534.1 ft. - General Photograph - AGGREGATE

  • General Photograph - PEELING/FLAKING

    642.2 ft. - General Photograph - PEELING/FLAKING

All inspections of P07769Work order 0618889

Observations (14)

DistanceCodeObservation
668.1SAV—
668.6MGOConn. @ Mh, 3 O' Clock. Active
355.5MGPPEELING/FLAKING
0MWM—
668.1SSS—
487.6MGPRAGS
0MWL—
0AMH8:30 AM
534.1MGPAGGREGATE
272.4MGPPEELING/FLAKING
642.2MGPPEELING/FLAKING
669.1AMH10:22 AM
0.1SAV—
0.1SSS—

Properties (3)

custom_field_two
3
customer
LACSD
datetime
2017-04-18T08:27:52-07:00
