Wastewater/Activity/PacpInspection/1.0Feb 27, 2017, 06:43 PM
B 0235_B 0234_2272017_110418.mp4
- Date
- 02/27/2017
- W/O
- 0626070
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z00077
- PipeID
- P08703
- Time
- 10:43 AM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7342
- Sewer Name
- B JOINT OUTFALL B - UNIT 1E
- City
- MONTEBELLO
- Loc. details
- Sidewalk
- Location Code
- F
- Use of Sewer
- Sanitary Sewer
- District
- District 02
- Page No.
- 11
- Purpose
- Maintenance Related
- Project
- 20170224DF_JOINT_OUTFALL_B_UNIT_1E
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 18 in.
- Upstream MH
- B 0235
- Downstream MH
- B 0234
- Dir. of Survey
- Downstream
- Length Surveyed
- 9.8 ft.
- Total Length
- 9.8 ft.
- Structural Index
- 4
- Structural Quick
- 4100
- Structural Rating
- 4
- O&M Index
- 4
- O&M Quick
- 4100
- O&M Rating
- 4
- Overall Index
- 4
- Overall Quick
- —
- Overall Rating
- 8
Observation photos (7)
0 ft. - Water Level, 100 %of cross sectional area
0 ft. - Upstream Manhole, Survey Begins - 10:45 AM
9.5 ft. - Broken, from 11 to 01 o'clock, within 8 inches of joint: YES - POSSIBLE BROKEN STUFFED WITH GREASE
9.5 ft. - General Photograph - POSSIBLE SOIL
9.5 ft. - General Photograph - BROKEN
9.8 ft. - Alignment Up, 45 %
9.8 ft. - Survey Abandoned - VIEW OF THE UPLEG PIPE OF THE D-S SIPHON
Observations (7)
| Distance | Code | Observation |
|---|---|---|
| 9.5 | B | POSSIBLE BROKEN STUFFED WITH GREASE |
| 9.8 | LU | — |
| 9.8 | MSA | VIEW OF THE UPLEG PIPE OF THE D-S SIPHON |
| 9.5 | MGP | POSSIBLE SOIL |
| 9.5 | MGP | BROKEN |
| 0 | MWL | — |
| 0 | AMH | 10:45 AM |
Properties (5)
- additional_info
- VIEW OF THE UPLEG PIPE OF THE DOWNSTREAM SIPHON
- custom_field_three
- POSSIBLE BROKEN PIPE
- custom_field_two
- 1
- customer
- LACSD
- datetime
- 2017-02-27T10:43:36-08:00
