Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Feb 21, 2017, 08:24 PM

  • C 0571_A 0831_2212017_123328.mp4

Date
02/21/2017
W/O
0613346
Weather
Dry
Operator/Surveyor
FRANKLIN
Sewer ID
Z00324
PipeID
P23446
Time
12:24 PM
Certificate
U-415-06024039
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7337
Sewer Name
A JOA-1A NORTH LONG BEACH INTERCEPTOR
City
LAKEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 03
Page No.
08
Purpose
Capital Improvement Program Assesment
Project
20170221DF_JOA_1A_NORTH_LONG_BEACH_INTERCEPTOR
Material
Vitrified Clay Pipe
Shape
Circular
Height
8 in.
Upstream MH
C 0571
Downstream MH
A 0831
Dir. of Survey
Downstream
Length Surveyed
2.1 ft.
Total Length
2.1 ft.
Structural Index
2
Structural Quick
3111
Structural Rating
4
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
2
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole C 0571 to A 0831
MH: C 0571MH: A 0831downstream0 ft. AMH - Downstream Manhole, Survey Begins - 12:29 PM0.1 ft. MGO - General Observation - Conn. @ Mh, 6 O' Clock. Active0.1 ft. MWL - Water Level, 5 %of cross sectional area0.1 ft. MWM - Water Mark, 10 %of cross sectional area2 ft. MGP - General Photograph2 ft. JOM - Joint Offset Medium2 ft. CM - Crack Multiple, from 12 to 04 o'clock, within 8 inches of joint: YES2.1 ft. AMH - Upstream Manhole, Survey Ends - 12:42 PM

Observation photos (2)

  • General Photograph

    2 ft. - General Photograph

  • Crack Multiple, from 12 to 04 o'clock, within 8 inches of joint: YES

    2 ft. - Crack Multiple, from 12 to 04 o'clock, within 8 inches of joint: YES

All inspections of P23446Work order 0613346

Observations (8)

DistanceCodeObservation
0AMH12:29 PM
0.1MGOConn. @ Mh, 6 O' Clock. Active
0.1MWL—
2MGP—
0.1MWM—
2JOM—
2CM—
2.1AMH12:42 PM

Properties (3)

custom_field_two
3
customer
LACSD
datetime
2017-02-21T12:24:18-08:00
