Wastewater/Activity/PacpInspection/1.0Nov 29, 2016, 08:55 PM
29 0306_29 0305_11292016_130103.mp4
- Date
- 11/29/2016
- W/O
- 0607759
- Weather
- Dry
- Operator/Surveyor
- FRANKLIN
- Sewer ID
- Z01015
- PipeID
- P24319
- Time
- 12:55 PM
- Certificate
- U-415-06024039
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7283
- Sewer Name
- 29 EASTSIDE INTERCEPTOR SEWER
- City
- SIGNAL HILL
- Loc. details
- Light Highway
- Location Code
- C
- Use of Sewer
- Sanitary Sewer
- District
- District 29
- Page No.
- 01
- Purpose
- Routine Assessment
- Project
- 20161129DF_EASTSIDE_INTERCEPTOR_SEWER
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Upstream MH
- 29 0305
- Downstream MH
- 29 0306
- Dir. of Survey
- Upstream
- Length Surveyed
- 343.6 ft.
- Total Length
- 343.6 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 0
- O&M Quick
- 0000
- O&M Rating
- 0
- Overall Index
- 0
- Overall Quick
- —
- Overall Rating
- 0
Observation photos (5)
168.4 ft. - General Observation - CHIPPING @ 3 O'CLOCK
201.2 ft. - General Observation - CHIPPING @ 10 O 'CLOCK
223.6 ft. - General Observation - CHIPPING @ 3 O'CLOCK
239.9 ft. - General Observation - CHIPPING @ 4 O'CLOCK
245.5 ft. - General Observation - CHIPPING FROM 3 TO 4 O'CLOCK
Observations (12)
| Distance | Code | Observation |
|---|---|---|
| 239.9 | MGO | GASKET HANGING OUT @ JOINT FROM 1 TO 3 O'CLOCK |
| 0 | AMH | 1:00 PM |
| 168.4 | MGO | CHIPPING @ 3 O'CLOCK |
| 223.6 | MGO | CHIPPING @ 3 O'CLOCK |
| 201.2 | MGO | CHIPPING @ 10 O 'CLOCK |
| 245.5 | MGO | CHIPPING FROM 3 TO 4 O'CLOCK |
| 343.6 | AMH | 1:25 PM |
| 0.1 | MWL | — |
| 239.9 | MGO | CHIPPING @ 4 O'CLOCK |
| 343.5 | MGO | Conn. @ Mh, 9 O' Clock. OPEN |
| 0.1 | MWM | — |
| 343.5 | MGO | Conn. @ MH 3 O'CLOCK OPEN |
Properties (3)
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-11-29T12:55:17-08:00
