Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Sep 3, 2016, 03:24 PM

  • 19 0193_19 0192_932016_082633.mp4

Date
09/03/2016
W/O
0591703
Weather
Dry
Operator/Surveyor
MIRANDA
Sewer ID
Z00726
PipeID
P15162
Time
8:24 AM
Certificate
U-1014-06022542
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7224
Sewer Name
19 NORWALK BOULEVARD TRUNK
City
LAKEWOOD
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 19
Page No.
07
Purpose
Routine Assessment
Project
20160902AM_NORWALK_BOULEVARD_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
21 in.
Upstream MH
19 0193
Downstream MH
19 0192
Dir. of Survey
Downstream
Length Surveyed
412.9 ft.
Total Length
412.9 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
2
O&M Quick
2100
O&M Rating
2
Overall Index
2
Overall Quick
—
Overall Rating
2
Pipe schematic from manhole 19 0193 to 19 0192
MH: 19 0193MH: 19 0192downstream0 ft. MGO - General Observation - ROACHES INSIDE THE MH.0 ft. MGO - General Observation - CAPPED CONN. INSIDE THE MH. @ 09 O'CLOCK0 ft. MWM - Water Mark, 15 %of cross sectional area0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 8:25 AM96 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start - POSSIBLE CALCIUM/GREASE411.7 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Finish - POSSIBLE CALCIUM/GREASE412.1 ft. MGO - General Observation - ROACHES INSIDE THE MH.412.9 ft. AMH - Downstream Manhole, Survey Ends - 8:41 AM

Observation photos (2)

  • Water Level, 10 %of cross sectional area

    0 ft. - Water Level, 10 %of cross sectional area

  • Deposits Attached Grease, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start - POSSIBLE CALCIUM/GREASE

    96 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 07 to 05 o'clock, , within 8 inches of joint: YES, Start - POSSIBLE CALCIUM/GREASE

All inspections of P15162Work order 0591703

Observations (9)

DistanceCodeObservation
0MGOROACHES INSIDE THE MH.
0MGOCAPPED CONN. INSIDE THE MH. @ 09 O'CLOCK
0MWM—
412.9AMH8:41 AM
96DAGSPOSSIBLE CALCIUM/GREASE
0MWL—
412.1MGOROACHES INSIDE THE MH.
0AMH8:25 AM
411.7DAGSPOSSIBLE CALCIUM/GREASE

Properties (3)

custom_field_two
4
customer
LACSD
datetime
2016-09-03T08:24:05-07:00
