Wastewater/Activity/PacpInspection/1.0Jul 27, 2016, 07:41 PM
29 0669_29 0668_7272016_124401.mp4
- Date
- 07/27/2016
- W/O
- 0579968
- Weather
- Very Dry
- Operator/Surveyor
- MIRANDA
- Sewer ID
- Z00537
- PipeID
- P24917
- Time
- 12:41 PM
- Certificate
- U-1014-06022542
- System Owner
- LACSD
- Date Cleaned
- —
- Pre-Cleaning
- Not Known
- Media Label
- G7189
- Sewer Name
- 29 21ST STREET SEWER
- City
- SIGNAL HILL
- Loc. details
- Other
- Location Code
- Z
- Use of Sewer
- Sanitary Sewer
- District
- District 29
- Page No.
- 04
- Purpose
- Routine Assessment
- Project
- 20160721AM_21ST_STREET_SEWER
- Material
- Vitrified Clay Pipe
- Shape
- Circular
- Height
- 8 in.
- Upstream MH
- 29 0668
- Downstream MH
- 29 0669
- Dir. of Survey
- Upstream
- Length Surveyed
- 139.9 ft.
- Total Length
- 139.9 ft.
- Structural Index
- 0
- Structural Quick
- 0000
- Structural Rating
- 0
- O&M Index
- 2
- O&M Quick
- 2100
- O&M Rating
- 2
- Overall Index
- 2
- Overall Quick
- —
- Overall Rating
- 2
Observation photos (2)
132.7 ft. - Deposits Attached Other, 5 %of cross sectional area, from 05 to 07 o'clock, , within 8 inches of joint: YES, Start - DEBRIS
138.7 ft. - General Observation - CAPPED CONN. INSIDE THE MH. @ 12 O'CLOCK, START OF THE LINE
Observations (13)
| Distance | Code | Observation |
|---|---|---|
| 138.7 | MGO | CAPPED CONN. INSIDE THE MH. @ 12 O'CLOCK, START OF THE LINE |
| 121.4 | TF | OPEN |
| 0 | AMH | 12:42 PM |
| 132.7 | DAZ | DEBRIS |
| 0 | MWL | — |
| 44.8 | TF | OPEN |
| 0 | MWM | — |
| 138.7 | MGO | ROACHES INSIDE THE MH. |
| 0 | MGO | ROACHES INSIDE THE MH. |
| 139.9 | AMH | 12:56 PM |
| 138.1 | DAZ | DEBRIS |
| 131.3 | TF | OPEN |
| 5.1 | TF | OPEN |
Properties (3)
- custom_field_two
- 4
- customer
- LACSD
- datetime
- 2016-07-27T12:41:10-07:00
