Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Mar 30, 2016, 07:30 AM

  • 05 1094_05 1093_3302016_014727.mp4

Date
03/30/2016
W/O
0557603
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00488
PipeID
P06328
Time
12:30 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0103
Sewer Name
05 MONETA EXTENSION TRUNK, SECTION 1
City
LAWNDALE
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
17
Purpose
Routine Assessment
Project
20160325MDM_MONETA_EXTENSION_TRUNK_SECTION_1
Material
Vitrified Clay Pipe
Shape
Circular
Height
12 in.
Upstream MH
05 1094
Downstream MH
05 1093
Dir. of Survey
Downstream
Length Surveyed
319.9 ft.
Total Length
319.9 ft.
Structural Index
2
Structural Quick
5138
Structural Rating
75
O&M Index
2
O&M Quick
2100
O&M Rating
2
Overall Index
2
Overall Quick
—
Overall Rating
77
Pipe schematic from manhole 05 1094 to 05 1093
MH: 05 1094MH: 05 1093downstream0 ft. MWL - Water Level, 10 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 1:40AM2 ft. MWM - Water Mark, 40 %of cross sectional area2 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start4.3 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - HAIRLINE23.7 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 6" - Active25.8 ft. FC - Fracture Circumferential, from 08 to 09 o'clock, within 8 inches of joint: YES - SLIGHT25.9 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - SLIGHT50 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - H50 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - SLIGHT65.4 ft. FC - Fracture Circumferential, from 11 to 02 o'clock, within 8 inches of joint: YES - SLIGHT65.4 ft. FL - Fracture Longitudinal, at 08 o'clock, within 8 inches of joint: YES - H65.4 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - H85.5 ft. FC - Fracture Circumferential, from 09 to 01 o'clock, within 8 inches of joint: YES - SLIGHT86.8 ft. FL - Fracture Longitudinal, at 01 o'clock, within 8 inches of joint: YES - H97.5 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H109.6 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H111.6 ft. FC - Fracture Circumferential, from 02 to 05 o'clock, within 8 inches of joint: YES - SLIGHT118 ft. FC - Fracture Circumferential, from 12 to 01 o'clock, within 8 inches of joint: YES - SLIGHT124.7 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 6" - Open129.9 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE161.2 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H173 ft. FC - Fracture Circumferential, from 08 to 11 o'clock, within 8 inches of joint: YES - H182 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - H191 ft. FL - Fracture Longitudinal, at 01 o'clock, within 8 inches of joint: YES - SLIGHT206.7 ft. FC - Fracture Circumferential, from 10 to 12 o'clock, within 8 inches of joint: YES - H215.4 ft. BSV - Broken Soil Visible, from 11 to 04 o'clock, within 8 inches of joint: YES - SOIL VISIBLE-MODERATE FRACTURE215.8 ft. MGP - General Photograph215.8 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - SLIGHT221.9 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - H224.8 ft. TF - Tap Factory Made, at 12 o'clock, -, within 8 inches of joint: YES, 6" - Active230.6 ft. FC - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE239.7 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - H252.2 ft. FC - Fracture Circumferential, from 12 to 04 o'clock, within 8 inches of joint: YES - SLIGHT264.1 ft. FL - Fracture Longitudinal, at 03 o'clock, within 8 inches of joint: YES - H280 ft. FC - Fracture Circumferential, from 01 to 04 o'clock, within 8 inches of joint: YES - SLIGHT291.9 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - SLIGHT307.5 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H310.4 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SLIGHT310.4 ft. FC - Fracture Circumferential, from 03 to 04 o'clock, within 8 inches of joint: YES - SLIGHT319.6 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Finish319.9 ft. AMH - Downstream Manhole, Survey Ends - 2:25AM

Observation photos (6)

  • Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

    2 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 03 to 09 o'clock, , within 8 inches of joint: YES, Start

  • Fracture Circumferential, from 02 to 05 o'clock, within 8 inches of joint: YES - SLIGHT

    111.6 ft. - Fracture Circumferential, from 02 to 05 o'clock, within 8 inches of joint: YES - SLIGHT

  • Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE

    129.9 ft. - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE

  • Broken Soil Visible, from 11 to 04 o'clock, within 8 inches of joint: YES - SOIL VISIBLE-MODERATE FRACTURE

    215.4 ft. - Broken Soil Visible, from 11 to 04 o'clock, within 8 inches of joint: YES - SOIL VISIBLE-MODERATE FRACTURE

  • General Photograph

    215.8 ft. - General Photograph

  • Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE

    230.6 ft. - Fracture Circumferential, from 08 to 12 o'clock, within 8 inches of joint: YES - MODERATE

All inspections of P06328Work order 0557603

Observations (42)

DistanceCodeObservation
97.5FLH
65.4FCSLIGHT
65.4FLH
0MWL—
23.7TFActive
239.7FCH
252.2FCSLIGHT
291.9FCSLIGHT
215.8MGP—
206.7FCH
173FCH
111.6FCSLIGHT
224.8TFActive
2MWM—
310.4FCSLIGHT
230.6FCMODERATE
129.9FCMODERATE
264.1FLH
65.4FCH
310.4FCSLIGHT
215.4BSVSOIL VISIBLE-MODERATE FRACTURE
25.9FCSLIGHT
182FCH
161.2FLH
50FCH
2DAGS—
124.7TFOpen
4.3FCHAIRLINE
307.5FLH
0AMH1:40AM
221.9FCH
319.9AMH2:25AM
25.8FCSLIGHT
109.6FLH
215.8FCSLIGHT
319.6DAGS—
118FCSLIGHT
280FCSLIGHT
86.8FLH
50FCSLIGHT
191FLSLIGHT
85.5FCSLIGHT

Properties (4)

custom_field_three
BROKEN PIPE SOIL VISIBLE=MODERATE FRACTURE
custom_field_two
1
customer
LACSD
datetime
2016-03-30T00:30:24-07:00
