Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Feb 17, 2016, 09:47 AM

  • 05 2570_05 2569_2172016_030940.mp4

Date
02/17/2016
W/O
0547039
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z01131
PipeID
P25271
Time
1:47 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0055
Sewer Name
05 COLDEN AVENUE RELIEF TRUNK
City
HUNTINGTON PARK
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 05
Page No.
11A
Purpose
Routine Assessment
Project
20160216MDM_COLDEN_AVENUE_RELIEF_TRUNK
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
05 2570
Downstream MH
05 2569
Dir. of Survey
Downstream
Length Surveyed
3 ft.
Total Length
3 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
4
Overall Quick
—
Overall Rating
4
Pipe schematic from manhole 05 2570 to 05 2569
MH: 05 2570MH: 05 2569downstream0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. MWL - Water Level, 50 %of cross sectional area - STANDING WATER & SLUDGE NO FLOW STOPLOG IN PLACE0 ft. AMH - Upstream Manhole, Survey Begins - 3:05AM2 ft. MGP - General Photograph - DOWNLEG SIPHON SOUTH3 ft. MSA - Survey Abandoned - DOWNLEG UPSTREAM SIPHON SOUTH

Observation photos (2)

  • Water Mark, 50 %of cross sectional area

    0 ft. - Water Mark, 50 %of cross sectional area

  • Survey Abandoned - DOWNLEG UPSTREAM SIPHON SOUTH

    3 ft. - Survey Abandoned - DOWNLEG UPSTREAM SIPHON SOUTH

All inspections of P25271Work order 0547039

Observations (5)

DistanceCodeObservation
0MWM—
3MSADOWNLEG UPSTREAM SIPHON SOUTH
0MWLSTANDING WATER & SLUDGE NO FLOW STOPLOG IN PLACE
0AMH3:05AM
2MGPDOWNLEG SIPHON SOUTH

Properties (4)

additional_info
DOWNLEG UPSTREAM SIPHON SOUTH
custom_field_two
4
customer
LACSD
datetime
2016-02-17T01:47:09-08:00
