Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 7, 2016, 08:32 AM

  • 02 1434_STACK_1172016_023311.mp4

Date
11/07/2016
W/O
0605768
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00349
PipeID
P08467
Time
12:32 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0336
Sewer Name
02 DISTRICT #2 INTERCEPTOR TRUNK
City
LOS ANGLES
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 02
Page No.
12
Purpose
Pre-Rehabilitation Survey
Project
20161107MDM_DISTRICT_2_INTERCEPTOR_TRUNK
Material
Reinforced Concrete Pipe
Shape
Circular
Height
48 in.
Upstream MH
02 1434
Downstream MH
STACK
Dir. of Survey
Downstream
Length Surveyed
9 ft.
Total Length
9 ft.
Structural Index
0
Structural Quick
0000
Structural Rating
0
O&M Index
0
O&M Quick
0000
O&M Rating
0
Overall Index
0
Overall Quick
—
Overall Rating
0
Pipe schematic from manhole 02 1434 to STACK
MH: 02 1434MH: STACKdownstream0 ft. AMH - Upstream Manhole, Survey Begins - 2:20AM1 ft. MGO - General Observation - FRAME2 ft. MGO - General Observation - GRADE RING& RAISER3 ft. MGO - General Observation - NORTH STACK4 ft. MGO - General Observation - SOUTH STACK5 ft. MGO - General Observation - NORTH WALL5.5 ft. MGO - General Observation - MH CONN ACTIVE NORTH WALL6 ft. MGO - General Observation - EAST WALL6.5 ft. MGO - General Observation - STOPLOG GROVES EAST WALL GOOD CONDITION7 ft. MGO - General Observation - SOUTH WALL7.5 ft. MGO - General Observation - MH CONN OPEN STOPLOG IN PLACE SOUTH WALL8 ft. MGO - General Observation - WEST WALL9 ft. MGO - General Observation - ROOF

Observation photos (12)

  • General Observation - FRAME

    1 ft. - General Observation - FRAME

  • General Observation - GRADE RING& RAISER

    2 ft. - General Observation - GRADE RING& RAISER

  • General Observation - NORTH STACK

    3 ft. - General Observation - NORTH STACK

  • General Observation - SOUTH STACK

    4 ft. - General Observation - SOUTH STACK

  • General Observation - NORTH WALL

    5 ft. - General Observation - NORTH WALL

  • General Observation - MH CONN ACTIVE NORTH WALL

    5.5 ft. - General Observation - MH CONN ACTIVE NORTH WALL

  • General Observation - EAST WALL

    6 ft. - General Observation - EAST WALL

  • General Observation - STOPLOG GROVES EAST WALL GOOD CONDITION

    6.5 ft. - General Observation - STOPLOG GROVES EAST WALL GOOD CONDITION

  • General Observation - SOUTH WALL

    7 ft. - General Observation - SOUTH WALL

  • General Observation - MH CONN OPEN STOPLOG IN PLACE SOUTH WALL

    7.5 ft. - General Observation - MH CONN OPEN STOPLOG IN PLACE SOUTH WALL

  • General Observation - WEST WALL

    8 ft. - General Observation - WEST WALL

  • General Observation - ROOF

    9 ft. - General Observation - ROOF

All inspections of P08467Work order 0605768

Observations (13)

DistanceCodeObservation
9MGOROOF
6.5MGOSTOPLOG GROVES EAST WALL GOOD CONDITION
2MGOGRADE RING& RAISER
1MGOFRAME
0AMH2:20AM
5.5MGOMH CONN ACTIVE NORTH WALL
3MGONORTH STACK
6MGOEAST WALL
8MGOWEST WALL
7MGOSOUTH WALL
7.5MGOMH CONN OPEN STOPLOG IN PLACE SOUTH WALL
5MGONORTH WALL
4MGOSOUTH STACK

Properties (3)

additional_info
TOPSIDE MANHOLE INSPECTION
customer
LACSD
datetime
2016-11-07T00:32:19-08:00
