Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Nov 4, 2016, 11:36 AM

  • C 0663_C 0662_1142016_044146.mp4

Date
11/04/2016
W/O
0596966
Weather
Dry
Operator/Surveyor
MARTIN
Sewer ID
Z00266
PipeID
P23929
Time
4:36 AM
Certificate
U-1014-06022543
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
H0333
Sewer Name
C JOINT OUTFALL C - UNIT 3F
City
SIGNAL HILL
Loc. details
Main Highway - Urban
Location Code
A
Use of Sewer
Sanitary Sewer
District
District 29
Page No.
01
Purpose
Routine Assessment
Project
20161104MDM_JOINT_OUTFALL_C_UNIT_3F
Material
Vitrified Clay Pipe
Shape
Circular
Height
18 in.
Upstream MH
C 0663
Downstream MH
C 0662
Dir. of Survey
Downstream
Length Surveyed
328.6 ft.
Total Length
328.6 ft.
Structural Index
2
Structural Quick
4137
Structural Rating
57
O&M Index
3
O&M Quick
5141
O&M Rating
13
Overall Index
3
Overall Quick
—
Overall Rating
70
Pipe schematic from manhole C 0663 to C 0662
MH: C 0663MH: C 0662downstream0 ft. MWM - Water Mark, 50 %of cross sectional area0 ft. MWL - Water Level, 5 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 4:40AM6.4 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - H6.4 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - HAIRLINE10.9 ft. FC - Fracture Circumferential, from 01 to 03 o'clock, within 8 inches of joint: YES - SLIGHT23.1 ft. FC - Fracture Circumferential, from 09 to 02 o'clock, within 8 inches of joint: YES - SL23.1 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - SL39.3 ft. FL - Fracture Longitudinal, at 11 o'clock, within 8 inches of joint: YES - H48.2 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL48.2 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - H69.3 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL93.6 ft. FC - Fracture Circumferential, from 12 to 02 o'clock, within 8 inches of joint: YES - SL94.8 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped100.5 ft. FC - Fracture Circumferential, from 11 to 01 o'clock, within 8 inches of joint: YES - SL121.3 ft. FM - Fracture Multiple, from 09 to 03 o'clock, within 8 inches of joint: YES - H125.4 ft. FC - Fracture Circumferential, from 10 to 02 o'clock, within 8 inches of joint: YES - H137.4 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H138.8 ft. TBC - Tap Break-In Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped144.9 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H153.2 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H169.7 ft. FL - Fracture Longitudinal, at 02 o'clock, within 8 inches of joint: YES - H181 ft. FC - Fracture Circumferential, from 09 to 10 o'clock, within 8 inches of joint: YES - SL181 ft. MGO - General Observation - 18" VCP192.3 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped218.9 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H218.9 ft. FC - Fracture Circumferential, from 02 to 04 o'clock, within 8 inches of joint: YES - SL222.7 ft. FL - Fracture Longitudinal, at 10 o'clock, within 8 inches of joint: YES - H245.4 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped271 ft. MWM - Water Mark, 80 %of cross sectional area275.5 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 02 to 10 o'clock, , within 8 inches of joint: YES, Start275.5 ft. FC - Fracture Circumferential, from 09 to 11 o'clock, within 8 inches of joint: YES - H298 ft. TFC - Tap Factory Made Capped, at 10 o'clock, -, within 8 inches of joint: YES, 6" - Capped298 ft. DAGS - Deposits Attached Grease, 5 %of cross sectional area, from 02 to 10 o'clock, , within 8 inches of joint: YES, Finish324.5 ft. FC - Fracture Circumferential, from 12 to 03 o'clock, within 8 inches of joint: YES - SL324.5 ft. FC - Fracture Circumferential, from 09 to 12 o'clock, within 8 inches of joint: YES - H328.1 ft. MGO - General Observation - Conn. @ Mh, 9 O' Clock. Active328.6 ft. AMH - Downstream Manhole, Survey Ends - 5:20AM

Observation photos (1)

  • Deposits Attached Grease, 5 %of cross sectional area, from 02 to 10 o'clock, , within 8 inches of joint: YES, Start

    275.5 ft. - Deposits Attached Grease, 5 %of cross sectional area, from 02 to 10 o'clock, , within 8 inches of joint: YES, Start

All inspections of P23929Work order 0596966

Observations (38)

DistanceCodeObservation
324.5FCSL
0MWM—
324.5FCH
275.5DAGS—
153.2FLH
192.3TFCCapped
222.7FLH
23.1FCSL
125.4FCH
245.4TFCCapped
138.8TBCCapped
48.2FCSL
218.9FLH
275.5FCH
94.8TFCCapped
0MWL—
144.9FLH
6.4FCH
218.9FCSL
181FCSL
48.2FCH
0AMH4:40AM
137.4FLH
121.3FMH
328.6AMH5:20AM
181MGO18" VCP
23.1FCSL
93.6FCSL
10.9FCSLIGHT
328.1MGOConn. @ Mh, 9 O' Clock. Active
169.7FLH
298TFCCapped
100.5FCSL
6.4FCHAIRLINE
69.3FCSL
271MWM—
39.3FLH
298DAGS—

Properties (4)

custom_field_three
SLIGHT FRACTURES
custom_field_two
3
customer
LACSD
datetime
2016-11-04T04:36:20-07:00
