Sanitation Districts of Los Angeles Countyt4 Spatial
Wastewater/Activity/PacpInspection/1.0Dec 15, 2015, 08:43 PM

  • 01 0742_01 0741A_12152015_124649.mp4

Date
12/15/2015
W/O
0541801
Weather
Dry
Operator/Surveyor
MIRANDA
Sewer ID
Z00205
PipeID
P01651
Time
12:43 PM
Certificate
U-1014-06022542
System Owner
LACSD
Date Cleaned
—
Pre-Cleaning
Not Known
Media Label
G7017
Sewer Name
01 COMPTON DISPOSAL TRUNK
City
COMPTON
Loc. details
Light Highway
Location Code
C
Use of Sewer
Sanitary Sewer
District
District 01
Page No.
20
Purpose
Routine Assessment
Project
20151215AM_COMPTON_DISPOSAL_TRUNK
Material
Reinforced Concrete Pipe
Shape
Circular
Height
24 in.
Upstream MH
01 0742
Downstream MH
01 0741A
Dir. of Survey
Downstream
Length Surveyed
157.6 ft.
Total Length
157.6 ft.
Structural Index
3
Structural Quick
3121
Structural Rating
5
O&M Index
4
O&M Quick
4100
O&M Rating
4
Overall Index
3
Overall Quick
—
Overall Rating
9
Pipe schematic from manhole 01 0742 to 01 0741A
MH: 01 0742MH: 01 0741Adownstream0 ft. MGO - General Observation - CAPPED CONN. INSIDE THE MH. @ 06 O'CLOCK0 ft. MWL - Water Level, 50 %of cross sectional area0 ft. MGO - General Observation - ROACHES INSIDE THE MH.0 ft. MGO - General Observation - ACTIVE CONN. INSIDE THE MH. @ 03 O'CLOCK0 ft. MWM - Water Mark, 55 %of cross sectional area0 ft. AMH - Upstream Manhole, Survey Begins - 12:44 PM2 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO, Start2 ft. MGO - General Observation - 70% MAG COAT, FROM 09 TO 03 O'CLOCK, START2 ft. SAV - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: NO, Start155.9 ft. SSS - Surface Spalling, from 09 to 03 o'clock, within 8 inches of joint: NO, Finish155.9 ft. MGO - General Observation - 70% MAG COAT, FROM 09 TO 03 O'CLOCK, FINISH155.9 ft. SAV - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: NO, Finish156.2 ft. MGO - General Observation - ROACHES INSIDE THE MH.156.2 ft. MGO - General Observation - ACTIVE CONN. INSIDE THE MH. @ 09 O'CLOCK157.6 ft. AMH - Downstream Manhole, Survey Ends - 1:13 PM

Observation photos (2)

  • Water Level, 50 %of cross sectional area

    0 ft. - Water Level, 50 %of cross sectional area

  • Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

    2 ft. - Surface Aggregate Visible, from 09 to 03 o'clock, within 8 inches of joint: NO, Start

All inspections of P01651Work order 0541801

Observations (15)

DistanceCodeObservation
156.2MGOROACHES INSIDE THE MH.
2SSS—
155.9SSS—
0MGOCAPPED CONN. INSIDE THE MH. @ 06 O'CLOCK
0MWL—
0MGOROACHES INSIDE THE MH.
157.6AMH1:13 PM
155.9MGO70% MAG COAT, FROM 09 TO 03 O'CLOCK, FINISH
0MGOACTIVE CONN. INSIDE THE MH. @ 03 O'CLOCK
156.2MGOACTIVE CONN. INSIDE THE MH. @ 09 O'CLOCK
0MWM—
2MGO70% MAG COAT, FROM 09 TO 03 O'CLOCK, START
155.9SAV—
0AMH12:44 PM
2SAV—

Properties (4)

custom_field_three
SEV. EXP. AGGREGATE
custom_field_two
3
customer
LACSD
datetime
2015-12-15T12:43:26-08:00
